FlexiEdge is a range of high-speed and fast action doors offering outstanding safety, durability, and weather resistance. Designed for high-frequency use, these rapid roll doors suit forklifts, pedestrians, and other vehicles. Trusted across Europe, they are ideal for warehousing, logistics, retail, manufacturing, airports, food processing, pharmaceuticals, and more - delivering reliable performance in any demanding environment.
Download BrochurePositive drive - The door curtain is securely driven when opening and closing via a toothed wheel engaging side belts. It performs smoothly under higher wind pressures, ideal for demanding conditions.
Low-friction drive - Low-friction side guides enable quieter operation. The door opens with a roller and closes gently under its own weight. Both systems avoid heavyweight components, enhancing safety and reducing maintenance needs.
Fast operation minimises open times, reducing heat loss, conserving energy, and lowering CO₂ emissions.
Energy savings lead to lower fuel bills and a shorter payback period. We offer cost analysis for specific installations to highlight potential savings.
Rapid operation maintains internal temperatures, improves working conditions, and limits the entry of noise, dust, pollution, and pests.
All doors are CE marked and comply with or exceed European harmonised standards, including EN 13241-1 for industrial, commercial, and garage doors.
All doors are custom-built to suit each project’s unique requirements. The table below provides an overview of the available range. Door sizes and speeds are indicative, with greater widths, heights, or speeds available for specific applications. For detailed information on weather performance, refer to our brochure.
| Model | Drive System | Size - Width x Height | Opening (m/s) | Closing (m/s) |
| M2 P | Positive | 5.5x5.5 | 2.4 | 1.2 |
| M3 P | Positive | 9.0x5.5 | 0.8 | 0.4 |
| D-501 P | Positive | 5.5x5.5 | 2.4 | 1.2 |
| Model | Drive System | Size - Width x Height | Opening (m/s) | Closing (m/s) |
| M2 AW | Positive | 5.5x5.5 | 2.4 | 1.2 |
| M3 AW | Positive | 8.5x5.5 | 0.8 | 0.4 |
| Model | Drive System | Size - Width x height | Opening (m/s) | Closing (m/s) |
| M2 C | Positive | 5.5x5.5 | 2.4 | 1.2 |
| M3 C | Positive | 11.0x5.5 | 0.8 | 0.4 |
| D-501 C | Positive | 5.5x5.5 | 2.4 | 1.2 |
| Model | Drive System | Size - Width x height | Opening (m/s) | Closing (m/s) |
| D-310 LF | Low Friction | 3.0x3.0 | 1.0 | 1.0 |
| D-313 LF | Low Friction | 3.5x3.5 | 2.7 | 0.5 |
| D-311 LF | Low Friction | 4.0x4.0 | 1.2 | 0.5 |
| Model | Drive System | Size - Width x Height | Opening (m/s) | Closing (m/s) |
| D-313 LF C | Low Friction | 3.5 x 3.5 | 2.7 | 0.5 |
| D-311 LF C | Low Friction | 4.0 x 4.0 | 1.2 (2.0*) | 0.5 |
| M2 E | Positive | 5.5 x 5.5 | 1.2 | 0.6 |
| D-303 LF E | Low Friction | 3.5 x 3.5 | 2.0 | 0.5 |
| M2F | Positive | 4.0 x 5.5 | 2.4 | 1.2 |
* Optional Speed
Fast operating speeds and mechanical reliability make these doors ideal for high-traffic areas, minimising open times for improved efficiency. All-weather models feature reinforced designs for exceptional wind resistance in exposed locations.
The fully flexible curtain with a soft bottom edge eliminates rigid elements, reducing injury risks. All doors include a photocell, and most models (except the D-310 LF) feature a wireless bottom-edge detector for added safety and convenience.
The flexible soft-edge curtain withstands vehicle collisions. If dislodged, the curtain automatically re-inserts into the side guides as the door opens.
A positive air seal on both sides and at the top, combined with a flexible bottom edge that self-adjusts to uneven floors, ensures exceptional sealing. This reduces heat loss, saves energy, and enhances efficiency.
A range of activation systems can be supplied to maximise the effectiveness of FlexiEdge high-speed doors:
|
Manuel - Push button pads incorporating auto timed close function are standard. Pull cord, both wired and wireless, and keyoperated switches are also available. |
 |
|
Photocells - Set on both sides of the doorway to initiate opening and closing, as well as providing additional safety. Typically mounted on posts or handrails to suit the flow of traffic. |
 |
|
Radar - Initiates opening and closing, and may also act as a safety detector. Detects both vehicle and pedestrian traffic. Normally fitted above or at one side of the doorway, and range can be set at up to 10m. Can be tuned to suit directional traffic flow and for object shape/size sensitivity. |
 |
|
Induction Loops - The door opens automatically with closure after a time delay. Induction loops are set in the floor on one or both sides of the doorway, and can be tuned to optimise operation for the type of traffic. Can also be configured to cut out the effect of passing cross traffic. Not actuated by pedestrians. |
 |
Our technical representatives are available across the UK to discuss your requirements and recommend the most suitable door types.
We provide detailed installation drawings and technical specifications, and all doors are installed by our fully trained, experienced engineers to ensure optimal performance!
